Martin® Manufactured Canoe Liners

Rugged construction, reliable performance, long wear life

Click above to explore in 3D

Martin®-grade quality and performance, mine-grade construction and durability

Installed inside conveyor transfer point skirtboards, Martin® Manufactured Canoe Liners absorb impact and abrasion and create a dam to shield the sealing system from the weight of the material load, prolonging the life of the seal.

Martin® Manufactured Canoe Liners feature a steel plate molded inside the urethane to prevent bond issues. Liners are also stackable to line higher drop chutes.

Built Tough

The unique design and rugged construction features a steel plate molded inside of the urethane to prevent bond issues that lead to component failure.

Adjustable

Mounting slots allow for adjustment over the life of the liner, ensuring that optimal sealing is maintained throughout the entire wear life to provide maximum return on your investment.

Lasts Longer

World-class manufacturing capabilities and high-quality materials deliver a reliable and long-lasting liner that exceeds expectations and delivers unmatched performance.

Manufactured Canoe Liner
